320
by Liaocheng Wit Solar New Energy Technology Co Ltd · China
Visit siteOn-Grid 225/320kW Type: On-Grid
Green Energy Score
76.1
100% profile complete
String Inverter320.0 kW99.02% peakMonitoringRS 485Bluetooth
0Upvotes
Overview
On-Grid 225/320kW Type: On-Grid
Key Specifications
Output Power
320.0 kW
Peak Efficiency
99.02%
Enclosure
IP66
Warranty
1 years
Max Input Voltage
1500 V
MPPT Range
50 – 1500 V
Launch Year
2025
Full Specifications
Product Identity
Name320
Slugliaocheng-wit-solar-new-energy-technology-co-ltd-320
ManufacturerLiaocheng Wit Solar New Energy Technology Co Ltd
CountryChina
CategoryString Inverter
Sub-categoryOn-Grid
DC Input
Input Channels2
MPPT Voltage Range50 – 1500 V
Max Input Voltage1500 V
Max Input Current40 A
AC Output
Rated Output Power320.0 kW
Rated Voltage800 V
Voltage Range640 – 920 V
Frequency45-65 Hz Hz
Max Output Current254 A
Power Factor0.8
Efficiency
Peak Efficiency99.02%
MPPT Efficiency98.52%
Night Power Consumption2000 mW
Protection & Environmental
Enclosure RatingIP66
Operating Temperature-30°C to 60°C
Physical
Weight116 kg
Dimensions870x1136x361 mm
Communication
RS 485Bluetooth
Module-Level Monitoring
Commercial
Price—
Warranty1 years
Launch Year2025
StatusAvailable
Regions & Certifications
Asia-PacificChina
Green Energy Score
Score76.1
Profile Completeness100%
